Waste Incinerator Model TS10 with wet scrubber system

Hiclover Waste Incinerator Model TS10 with Wet Scrubber System: A Comprehensive Overview

The Hiclover Waste Incinerator Model TS10 is a state‐of‐the‐art solution engineered for efficient waste destruction with minimal environmental impact. Integrating a high-temperature combustion process with a sophisticated wet scrubber system, the TS10 is ideal for handling various types of waste—including medical, hazardous, and general waste—while ensuring that harmful emissions are significantly reduced.

Advanced Incineration Technology

At the core of the TS10’s design is its dual combustion chamber system. The primary combustion chamber, with a capacity of 100 liters and internal dimensions of 50×50×40 cm, reaches temperatures between 800℃ and 1000℃ to ensure rapid and complete combustion of incoming waste. A secondary chamber, rated at 50 liters, further elevates the temperature to between 1000℃ and 1300℃, ensuring that any remaining combustible materials are thoroughly burned. This dual-stage process not only maximizes burning efficiency—often exceeding 98%—but also minimizes the production of harmful residues and ash.

The TS10 is controlled via an advanced Programmable Logic Controller (PLC) system, which automates critical functions such as temperature monitoring, burner operation, and safety alerts. This ensures reliable performance, ease of operation, and precise regulation of the incineration process, thereby reducing the risk of operator error and enhancing overall safety

Integrated Wet Scrubber System

A key feature that sets the Hiclover TS10 apart is its integrated wet scrubber system, often referred to as the spray tower combined with a defogging tower. This system plays a pivotal role in controlling emissions:

• Pollutant Removal: As the incinerator operates, the combustion process generates flue gases that may contain particulate matter and other pollutants. The wet scrubber system uses a high-pressure water spray to capture and condense these particles, drastically reducing airborne emissions.
• Cooling and Defogging: The scrubber not only cools the flue gases before they are released into the atmosphere but also eliminates any visible fog or vapor, ensuring that the exhaust complies with strict environmental regulations.
• Enhanced Safety: By reducing the amount of fly ash and particulate matter released, the wet scrubber helps protect both the environment and public health, making it a crucial component for facilities handling hazardous or medical waste.

This combination of high-efficiency incineration and robust emission control makes the TS10 a reliable solution for institutions that must adhere to stringent environmental standards

Technical Specifications at a Glance

• Burn Rate: 10–20 kg per hour
• Feed Capacity: Approximately 20 kg per feeding
• Control Mode: Automated PLC control ensures precise operation
• Combustion Chambers:
  • Primary: 100 L capacity (50×50×40 cm)
  • Secondary: 50 L capacity
• Operating Voltage & Power: 220V with a power consumption of around 3.0 kW
• Fuel Flexibility: Capable of operating on natural gas, LPG, or diesel, providing versatility across different operational environments
• Chimney: Constructed from stainless steel (Type 304) with a height of 3 meters to ensure effective dispersion of exhaust gases
• Additional Features:
  • Temperature monitor with corundum probe tubes
  • Automatic cooling and false alarm systems
  • LCD display for progress tracking and time setting
  • A robust 200 L oil tank with liquid level indicators

These features ensure that the TS10 not only meets the rigorous demands of waste incineration but also provides an environmentally responsible approach to waste management.

Benefits and Applications

The Hiclover TS10 incinerator is designed to serve a wide range of applications, including:

• Medical Waste Disposal: Its high-temperature combustion and effective scrubber system are ideally suited for the safe destruction of infectious and hazardous medical waste.
• Hazardous Waste Management: By ensuring near-complete combustion and capturing residual pollutants, the TS10 reduces the environmental footprint associated with hazardous waste incineration.
• Remote and Mobile Installations: The compact dimensions and containerized design options allow for easy transport and deployment in remote areas or temporary facilities, including military and emergency response settings.

With its efficient fuel consumption, automated control systems, and rigorous emission controls, the TS10 is a cost-effective and environmentally responsible solution for modern waste management challenges.

Conclusion

In a world increasingly focused on sustainability and environmental protection, the Hiclover Waste Incinerator Model TS10 stands out as an advanced solution for waste treatment. Its innovative design, featuring a dual combustion system coupled with a cutting-edge wet scrubber, provides unmatched performance in both waste destruction and emission control. For organizations seeking a reliable, efficient, and environmentally compliant incineration system, the TS10 offers a comprehensive package that meets and exceeds industry standards

Whether used in hospitals, industrial facilities, or mobile waste management units, the Hiclover TS10 delivers consistent performance and peace of mind—making it a cornerstone in the evolution of modern incineration technology.

For more detailed specifications and product inquiries, please visit Hiclover’s official website or contact their sales team directly.
