Riello Light oil burner One stage operation 464T1 Model G10 LC

Thermal power – output 54 – 120 kW – 4.5 – 10 kg/h

Fuel Light oil, viscosity 4 – 6 mm2/s at 20°C

Electrical supply Single phase, 230V ± 10% ~ 50Hz

Motor Run current 0.8A – 2850 rpm – 298 rad/s

Capacitor 4 μF

Ignition transformer Secondary 8 kV – 16 mA

Pump Pressure 7 – 15 bar

Absorbed electrical power 0.170 kW
