Model TS50 Waste Incinerator

Incinerator Items/Model

HICLOVER TS50

Burn Rate (Average)

50-100kg/hour

Feed Capacity(Average)

50-100kg/feeding

Control Mode

PLC Automatic

Intelligent Sensor

Continuously Feeding with Worker Protection

High Temperature Retention

Yes (Adjustable)

Primary Combustion Chamber

560L

Internal Dimensions

100x80x70cm

Secondary Chamber

280L

Smoke Filter Chamber

Yes

Feed Mode

Manual

Voltage

220V

Power

0.7Kw

Burner Type

Italy Brand

Oil Consumption (kg/hour)

12-16

N.Gas Consumption (m3n/hour)

***

Temperature Monitor

Yes

Temperature Thermometer

Corundum Probe Tube, 1400℃Rate.

Automatic Cooling

Yes

Automatic False Alarm

Yes

Automatic Protection Operator(APO)

Yes

System Testing Model

Yes

Time Setting

Yes

Progress Display Bar and Time

LCD Display

Oil Tank

200L

Oil Tank Stand

Yes

Liquid level Display

Yes

Feeding Door

45x45cm

Chimney

3Meter

Chimney Type

Stainless Steel 304

1st. Chamber Temperature

800℃--1000℃

2nd. Chamber Temperature

1000℃-1300℃

Residency Time

2.0 Sec.

Gross Weight

5000kg

External Dimensions

230x130x155cm

1st. Chamber Composition Hot Face

Thickness: ≥115 mm

55% of Al203

1750°C Grade

2nd. Chamber Composition Hot Face

Thickness: ≥115 mm

75% of Al203

1790°C Grade

Chamber Cold Face Material

High Rate Refractory Ceramic Fiber

Other Parts Hot Face Refractory

Heavy Duty with steel fiber

Burner operation

Automatic On/Off

Dry Scrubber

Including

Wet Scrubber

Optional

Top Loading Door

Optional

Paint for outside face

250°C Grade

Sealing Material

Refractory Ceramic Fiber

Upgrade Containerized Mobile Type

Optional

CE Certificate

CE(2006/42/EC,2014/30/EU

ISO Certificate

ISO9001:2015

High-tech Enterprise Certificate

Yes
