Model TS100(PLC)  Waste Incinerator with S.Steel Wet scrubber(spray tower)
+2

Model TS100(PLC) Waste Incinerator with S.Steel Wet scrubber(spray tower)

Home/Store/Waste Incinerators
$23 000.00
Have questions?
Store Link: https://www.haiwos.com/
ShareSharePin it
Model TS100(PLC) Waste Incinerator with S.Steel Wet scrubber(spray tower)
Home/Store/Waste Incinerators
Store Link: https://www.haiwos.com/ ***Product Details (***Please Sign In or Login to "My Account". Price is the EXW Factory Term price or send email to us get discount if possible and get shipping cost for delivery by CIF/C&F/FOB term: sales@hiclover.com***) WhatsApp on Mobile: +8613813931455

Incinerator Items/Model

HICLOVER TS100(PLC)

Burn Rate (Average)

100-150 kg/hour

Feed Capacity(Average)

200kg/feeding

Control Mode

PLC Automatic

Primary Combustion Chamber

1200Liters(1.2m3)

Internal Dimensions

120x100x100cm

Secondary Chamber

600L

Smoke Filter Chamber

Yes

Feed Mode

Manual

Voltage

220V

Power

0.7Kw

Burner Type

Italy Brand

Oil Consumption (kg/hour)

16

N.Gas Consumption (m3n/hour)

***

Temperature Monitor

Yes

Temperature Thermometer

Corundum Probe Tube, 1400℃Rate.

Temperature Protection

Yes

Automatic Cooling

Yes

Automatic False Alarm

Yes

Automatic Protection Operator(APO)

Yes

System Testing Model

Yes

Time Setting

Yes

Progress Display Bar

LCD Display

Oil Tank

200L

Oil Tank Stand

Yes

Liquid level Display

Yes

Feeding Door

70x70cm

Chimney

8Meter

Chimney Type

Stainless Steel 304

1st. Chamber Temperature

800℃--1000℃

2nd. Chamber Temperature

1000℃-1300℃

Residency Time

2.0 Sec.

Gross Weight

6000kg

External Dimensions

260x150x180cm

1st. Chamber Composition Hot Face

Thickness: ≥115 mm

55% of Al203

1750°C Grade

2nd. Chamber Composition Hot Face

Thickness: ≥115 mm

75% of Al203

1790°C Grade

Chamber Cold Face Material

High Rate Refractory Ceramic Fiber

Other Parts Hot Face Refractory

Heavy Duty with steel fiber

Burner operation

Automatic On/Off

Dry Scrubber

Including

Wet Scrubber

Optional

Top Loading Door

Optional

Paint for outside face

250°C Grade

Sealing Material

Refractory Ceramic Fiber

Upgrade Containerized Mobile Type

Optional

CE Certificate

CE(2006/42/EC,2014/30/EU

ISO Certificate

ISO9001:2015

High-tech Enterprise Certificate

Yes


As urban populations grow, managing municipal waste has become an increasing challenge. Traditional landfill methods are proving to be unsustainable due to environmental and space constraints. Solid waste incinerators offer a viable solution, reducing waste volume, mitigating environmental impact, and ensuring efficient waste disposal. HICLOVER, a leading manufacturer of waste incineration solutions, provides state-of-the-art incinerators designed to handle municipal waste effectively.

Understanding Solid Waste Incineration

Solid waste incineration is a controlled combustion process that converts waste into ash, flue gas, and heat. This method significantly reduces waste volume, neutralizes hazardous components, and can even provide energy recovery benefits. HICLOVER’s incinerators are engineered to burn municipal solid waste (MSW) efficiently, ensuring compliance with environmental standards.

Features of HICLOVER Solid Waste Incinerators

HICLOVER designs advanced solid waste incinerators equipped with cutting-edge technology to meet diverse needs. Key features include:

  • Multiple Combustion Chambers: Ensures complete waste combustion and minimizes harmful emissions.
  • Fuel Type Options: Diesel, Natural Gas, and LPG fuel choices to meet various operational requirements.
  • Advanced PLC Control System: Allows automated and user-friendly operation.
  • Wet Scrubber System: Optional wet scrubber systems to control air pollution.
  • Italy-Brand Burners: Reliable and efficient combustion.
  • High-Temperature Retention (HTR): Ensures optimal incineration and reduces environmental impact.

Application of Solid Waste Incinerators in Municipal Waste Management

Municipal solid waste comprises various materials, including household, commercial, and institutional waste. HICLOVER incinerators cater to diverse waste streams, ensuring complete and environmentally safe waste disposal. Our incinerators are widely used in:

  • City Waste Management Facilities
  • Hospitals and Healthcare Centers
  • Industrial and Commercial Complexes
  • Camps, UN and WHO Facilities, and Crisis Zones

Technical Specifications

HICLOVER incinerators are available in multiple configurations, catering to different waste disposal needs:

  • Burning Rate (Capacity): Ranges from 5 kg to 1000 kg per hour per set.
  • Chamber Size: From 100 liters to 6000 liters.
  • Feeding Door Options: Side, Front, or Top-loading configurations.
  • Containerized, Trailer, and Sledge-type Incinerators: Portable and flexible solutions for various environments.
  • Burnable Waste Types: Medical, Animal, Solid, and other hazardous waste.
  • Spare Parts and PPE: Ensures operator safety and equipment longevity.

Benefits of HICLOVER Solid Waste Incinerators

  1. Efficient Waste Reduction: Reduces waste volume by up to 90%.
  2. Environmentally Friendly: Advanced emission control technologies ensure compliance with environmental regulations.
  3. Energy Recovery Capabilities: Heat recovery functions can be utilized for auxiliary purposes.
  4. User-Friendly Operation: Automated systems enhance ease of use and safety.
  5. Customizable Solutions: Tailored to meet specific municipal waste management needs.

Global Clientele

HICLOVER’s solid waste incinerators are trusted worldwide, with deployments in:

  • Afghanistan, Somalia, Oman, East Timor, Ethiopia, Mauritius, Pakistan, Papua New Guinea, Burundi, Australia, Germany, Macau, Indonesia, Eritrea, Moldova, Netherlands, Kazakhstan, Haiti, Vietnam, Cameroon, UAE, Kenya, Sri Lanka, Rwanda, Senegal, Mali, Thailand, America, Tanzania, Myanmar, Venezuela, Morocco, Spain, Nigeria, Equatorial Guinea, India, New Zealand, Iraq.
  • United Nations (UN), UNDP, World Bank, Oil fields, refugee camps, peacekeeping force camps, and crisis management sites.

Contact Us

For more information on our solid waste incinerators, visit our website at www.hiclover.com or contact us at sales@hiclover.com / hicloversales@gmail.com.

Send a simple message directly: Message Us

Submit general technical or commercial requirements: Request for Quote

External References and Product Links

  • Solid Waste Incinerator Catalogue: Download Here
  • Product Links:
    • Mobile Incinerators
    • Incinerator Spare Parts
    • Wet Scrubber Systems
    • Animal Cremation Incinerators
    • Waste Management Solutions

Conclusion

HICLOVER’s solid waste incinerators provide an efficient, eco-friendly, and sustainable waste management solution. By integrating advanced combustion technologies, customizable configurations, and strict environmental compliance, our incinerators ensure effective waste reduction. Contact us today to explore our wide range of municipal solid waste incinerators designed to meet the needs of modern waste management.

For more details, visit www.hiclover.com or call +86-13813931455 (WhatsApp Available).
