Incinerator for Rural health Clinics
Combustion Chamber Volume (m3): 1.25m3
Burn Rate*: up to 100kg per hour
Average Fuel Consumption: 13 - 18 litres p/h
Time To Temp: 45-60 mins
Operational Temperature: 850 - 1200°C
Gas Retention in Secondary Chamber: 2 secs
Loading Method: TOP Load
Fuel Options: Light Oil or Gas/LPG
Electricity Supply: 110v or 230v
Temperature Monitoring: Yes
Average ash residue (%): 3%
Thermostatic Device: Yes
PHYSICAL SPECIFICATIONS
External Length (mm): 1850mm
External Width (mm): 1110mm
External Height (mm): 8100mm
Door Size (mm); 640 x 540 mm
Shipping Weight: 6000kg
Operating Footprint: 23.22m2
Cool Touch Cladding: Yes
Incinerator Items/Model |
HICLOVER TS100(PLC) |
Feeding Door Location |
Top Loading |
Burn Rate (up to) |
100 kg/hour,medical waste incineration |
Control Mode |
PLC Automatic |
Primary Combustion Chamber |
1250L(1.25M3) |
Primary Combustion Chamber Internal Dimensions |
1400x700x1280mm |
Secondary Combustion Chamber |
600L(0.6m3) |
Feed Mode |
Manual |
Voltage |
220-240V |
Power |
1.0Kw |
Burner Type |
Italy Brand Riello |
Diesel Oil Consumption (Ltrs/hour) |
13-18 |
N.Gas/LPG Consumption (m3n/hour) |
*** |
Temperature Monitor |
Yes |
Time to Temperature |
45-60 mins,small waste incinerator |
Temperature Thermometer |
Corundum Probe Tube, 1400℃Rate. |
Temperature Protection |
Yes |
Automatic Cooling |
Yes |
Automatic False Alarm |
Yes |
Automatic Protection Operator(APO) |
Yes |
System Testing Model |
Yes |
Time Setting |
Yes |
Progress Display Bar/Timing |
LCD Display |
Oil Tank |
200L |
Oil Tank Stand |
Yes |
Liquid level Display |
Yes |
Top Feeding Door |
640x540mm |
Chimney |
5Meter |
Chimney Type |
Stainless Steel 304 |
Operational Temperature |
850℃--1300℃ |
Average ash residue (%) |
3% |
Thermostatic Device |
Yes |
Residency Time |
2.0 Sec. |
Gross Weight(Average) |
6000kg(6.0Ton) |
External Dimensions(Main Body) |
1850x1110x8100mm |
1st. Chamber Composition Hot Face |
High Alumina Refractory Brick Thickness: ≥115 mm |
55% of Al203 |
|
1750°C Grade |
|
2nd. Chamber Composition Hot Face |
High Alumina Refractory Castable Wall Thickness: ≥150 mm |
60% of Al203 |
|
1790°C Grade |
|
Chamber Cold Face Material |
High Rate Refractory Ceramic Fiber 50mm |
Other Parts Hot Face Refractory |
Heavy Duty with steel fiber |
Burner operation |
Automatic On/Off |
Wet Scrubber |
Optional |
Top Loading Door |
YES |
Paint for outside face |
250°C Grade |
Sealing Material |
Refractory Ceramic Fiber |
CE Certificate |
CE(2006/42/EC,2014/30/EU |
ISO Certificate |
ISO9001:2015 |
When it comes to providing dignified, respectful, and environmentally sound pet cremation services, finding affordable pet cremation incinerators for animal services is crucial. At HICLOVER (Nanjing Clover Medical Technology Co., Ltd), we design and manufacture innovative incineration solutions that not only meet but exceed industry standards. Our incinerators are engineered to process a variety of wastes—including pet and animal remains—with efficiency, safety, and minimal environmental impact.
Visit our website at www.hiclover.com or call us at +86-13813931455 for inquiries. You can also send us a message directly via our Simple Message Form or submit your requirements through our General Technical/Commerce RFQ.
Pet cremation services have become increasingly important as communities seek compassionate and sustainable ways to handle animal remains. The demand for affordable pet cremation incinerators for animal services continues to rise, driven by:
At HICLOVER, we leverage cutting-edge technology to produce incinerators with features such as PLC automatic control, intelligent sensor systems, and multiple combustion chambers to ensure complete and clean incineration.
Our incinerators are designed with flexibility and functionality in mind. The systems include several advanced optional and standard features, ensuring that our equipment meets diverse operational needs:
For an in-depth look at our technical specifications and product features, please refer to our detailed Waste Incinerator Catalogue.
Affordable pet cremation incinerators for animal services by HICLOVER are designed specifically to address the unique needs of pet crematoriums, veterinary clinics, and animal shelters. Our systems offer:
Our technology is trusted worldwide by organizations in countries including Afghanistan, Somalia, Oman, Ethiopia, Pakistan, Australia, Germany, and even challenging environments like war zones and crisis management sites. Our products have also been deployed in UN, WHO, and World Bank projects, ensuring that our incinerators meet rigorous international standards.
HICLOVER’s incinerators incorporate various technical optional items and functions to deliver the best performance:
For more details on our technical specifications and product variations, please review our Waste Incinerator Catalogue.
We proudly offer a comprehensive range of incineration products tailored for pet cremation and broader waste management solutions. Some featured products include:
These products are crafted with precision to ensure efficiency, durability, and ease of use, making them the preferred choice for animal services worldwide.
Our solutions have been implemented in diverse markets and challenging environments:
This extensive experience and diverse customer base underscore the reliability and versatility of our incineration systems.
For further insights into incineration technologies and waste management solutions, explore these trusted external resources:
Also, check out our website sitemap for easy navigation of our content.
HICLOVER stands out as a leading manufacturer and exporter of waste incinerators, including specialized pet cremation units, by offering:
For any inquiries or to request a quotation, please contact us at +86-13813931455 or via email at sales@hiclover.com and hicloversales@gmail.com.
Providing affordable, efficient, and environmentally responsible pet cremation services is not only a business necessity but also a social responsibility. At HICLOVER, our incinerators are engineered to support animal services with robust performance, innovative features, and cost-effective solutions.
If you are looking for affordable pet cremation incinerators for animal services, explore our comprehensive range and learn how our products can enhance your operations. Visit www.hiclover.com today to discover more about our technology and to access detailed product information.
For a deeper dive into our offerings, check out our Waste Incinerator Catalogue and connect with our expert team for personalized support.
Contact us now and join the global movement towards dignified, efficient, and environmentally responsible pet cremation services
