Incinerator HICLOVER TS300 300-500 kg/hour
$39 000.00
Waste Incinerators
Incinerator HICLOVER TS300 300-500 kg/hour
Incinerator HICLOVER TS300 300-500 kg/hour
Store Link: https://www.haiwos.com/ ***Product Details (***Please Sign In or Login to "My Account". Price is the EXW Factory Term price or send email to us get discount if possible and get shipping cost for delivery by CIF/C&F/FOB term: sales@hiclover.com***) WhatsApp on Mobile: +8613813931455
Incinerator HICLOVER TS300 300-500 kg/hour
|
Incinerator Items/Model |
HICLOVER TS300(PLC) |
|
Burn Rate (Average) |
300-500 kg/hour |
|
Feed Capacity(Average) |
500kg/feeding |
|
Control Mode |
PLC Automatic |
|
Intelligent Sensor |
Continuously Feeding with Worker Protection |
|
High Temperature Retention(HTR) |
Automatic (Temperature Adjustable) |
|
Intelligent Save Fuel Function |
Yes |
|
Heat Heart Technology(HHT) |
Optional |
|
Pre-Heat Fuel Saving(Heat Recovery) |
Optional |
|
Dual Control Mode |
Optional |
|
Fire Grate |
Optional |
|
Primary Combustion Chamber |
2340Liters(2.34m3) |
|
Internal Dimensions |
1800x1300x1000mm |
|
Secondary Chamber |
1000Liters(1.0m3) |
|
Feed Mode |
Manual |
|
Voltage |
220V |
|
Power |
3.0Kw |
|
Burner Type |
Italy Brand |
|
Oil Consumption (kg/hour) |
30-50 |
|
N.Gas Consumption (m3n/hour) |
*** |
|
Temperature Monitor |
Yes |
|
Temperature Thermometer |
Corundum Probe Tube, 1600℃Rate. |
|
Temperature Protection |
Yes |
|
Automatic Cooling |
Yes |
|
Automatic False Alarm |
Audio/Visual/Screen |
|
System Testing Model |
Yes |
|
Time Setting |
Yes |
|
Display Screen |
3.7 in” LCD Screen |
|
Progress Display Bar |
Yes |
|
Oil Tank |
200L |
|
Oil Tank Stand |
Yes |
|
Liquid level Display |
Yes |
|
Feeding Door |
100x100cm |
|
Feeding Door Location |
Default: Side Feeding Door Optional: Front/Top Feeding Door, Wet scrubber |
|
Chimney |
lined stacks height is 1Meter, steelstacks height is 7meter |
|
Chimney Type |
Steel |
|
1st. Chamber Temperature |
800℃--1000℃ |
|
2nd. Chamber Temperature |
1000℃-1300℃ |
|
Residency Time |
2.0 Sec. |
|
Gross Weight |
10000kg |
|
External Dimensions |
4200x1900x2800mm(without chimney) |
|
1st. Chamber Composition Hot Face |
High alumina refractory brick Thickness: ≥115 mm |
|
Composition 65% of Al203 |
|
|
1750°C Grade |
|
|
2nd. Chamber Composition Hot Face |
High alumina refractory brick Thickness: ≥115mm |
|
Composition 65% of Al203 |
|
|
1750°C Grade |
|
|
Chamber Cold Face Material |
High Rate Refractory Ceramic Fiber |
|
Other Parts Hot Face Refractory |
Heavy Duty with steel fiber |
|
Burner operation |
Automatic On/Off |
|
Wet Scrubber |
Optional |
|
Top Loading Door |
Optional |
|
Front Loading Door |
Optional |
|
Side Loading Door |
Default |
|
Paint for outside face |
250°C Grade |
|
Sealing Material |
Refractory Ceramic Fiber |
|
Upgrade Containerized Mobile Type |
Optional |
|
CE Certificate |
CE(2006/42/EC,2014/30/EU |
|
ISO Certificate |
ISO9001:2015 |
|
High-tech Enterprise Certificate |
Yes |
Incinerator HICLOVER TS300 300-500 kg/hour
the main difference of standard and containerized mobile is container, pre-mounted and mobile function.
containerized mobile function is free-installation(still few work have to do at local site, chimney hole/chimney installation and fuel connected). if standard incinerator, there will be several parts assembly, electric/fuel/chimney connection and main working is incineration plant house foundation,building,etc.
the mobile funciton: you can move to other place when emergency require, different place service, working base change,etc.
the container type according to differenet model, for this model have to be side opening type container as you see in the picture. it's same size as 20' full container.
when we delivery, the incinerator and container delivery to you together, you can get both of them. donot need other container when delivery if containerized mobile.
if you donot purchase containerized mobile type, the incinerator load into container and the container have to return shipping company when you get the incinerator.
