HICLOVER TS50 Containerized Mobile Incineration System

50 kg/hour Class | Dual-Chamber Combustion | Multi-Stage Wet Scrubbing | Plug-and-Play Container Unit

The HICLOVER TS50 Containerized Incineration System is a fully self-contained waste-treatment solution designed for rapid deployment, field mobility, and reliable operation in remote or infrastructure-limited environments. Built inside a standard ISO container, the TS50 provides safe medical-waste incineration and clean exhaust-gas purification through an integrated two-stage combustion system and multi-stage wet scrubber.

This configuration ensures reliable, emissions-compliant waste treatment for rural hospitals, field clinics, military camps, emergency missions, NGO operations, mining bases, and temporary waste stations, while maintaining the ease of transport, protection, and operational readiness expected from a container-based unit.

1. System Application

The mobile containerized TS50 is engineered for locations requiring quick installation, relocation flexibility, and 24/7 protected operation. Typical deployment scenarios include:

• Field hospitals & emergency medical centers
• Remote clinics and rural district health facilities
• Disaster-relief operations (WHO, UN, NGO missions)
• Refugee or humanitarian camps
• Military and peacekeeping bases
• Temporary quarantine stations
• Small municipal waste points
• Mining and construction camps

The system handles diverse waste streams:

• Infectious waste & PPE
• Sharps and contaminated materials
• Pathological samples (small volume)
• Laboratory waste
• General medical & clinic waste
• Light domestic waste

2. Containerized System Architecture

ISO Container Platform

The TS50 is installed inside a 20-foot or 40-foot ISO container, with the following enhancements:

• Reinforced internal steel floor
• Heat-resistant chimney penetration point
• Access doors for maintenance and waste loading
• Factory-installed electrical wiring and lighting
• Forklift pockets & corner castings for global transport
• Anti-corrosion exterior coating for coastal/tropical climates

Operational Benefit

The container design allows the entire incinerator and scrubber system to operate without a building, reducing civil work and ensuring mobility.

3. TS50 Combustion System (Inside the Container)

3.1 Primary Combustion Chamber

• Chamber volume ≈ 0.56 m³
• Waste throughput: ~50 kg/h
• Manual front-loading door with secure latch
• High-temperature diesel burner for stable combustion
• Designed for medical waste and mixed waste streams

3.2 Secondary Combustion Chamber

• High-temperature zone operating at 850–1100°C
• Dedicated secondary burner for complete smoke oxidation

•


3.3 Fuel Options

• Diesel (standard)
• LPG or Natural Gas (optional)

3.4 PLC Control System

• Chamber temperature monitoring
• Burner automation and safety interlocks
• Emergency stop / alarm functions
• Minimal operator training required

4. Integrated Wet Scrubbing & Filtration System

The exhaust treatment system may be installed inside or beside the container, depending on layout.

4.1 First-Stage Spray Tower (Primary Scrubber)

• Rapid cooling of hot flue gas
• Internal Pall Rings for large gas–liquid contact surface
• Removal of coarse dust and soot

4.2 Second-Stage Spray Tower (Secondary Scrubber)

• Additional Pall Ring packing
• Removal of fine particles, acidic vapors, and aerosols
• Stabilized gas output to ID fan

4.3 Demisting Tower

Demisting Tower is a dedicated final-stage purification component designed to remove fine mist droplets, aerosol particles, and moisture residues from the flue gas after wet scrubbing. Installed downstream of the spray towers, it ensures the exhaust gas discharged into the atmosphere is clean, dry, and compliant with environmental standards.

4.4 G4 Stainless-Steel Mesh Filter

• Final polishing filter
• Captures micro-mist and fine droplets
• Reusable, made from 304 stainless steel

4.5 Induced Draft Fan (ID Fan)

• Maintains stable negative pressure inside the container
• Ensures consistent airflow across the combustion and scrubbing system

5. Materials & Manufacturing Quality

• Container and system components fabricated from 304/316 stainless steel
• Refractory lining with high-alumina insulation inside combustion chambers
• Corrosion-resistant pipework and structural supports
• Weather-protected external fittings
• Designed for long-term service in harsh climates (tropical, desert, coastal)

6. Performance Specifications

7. Key Advantages of the Containerized TS50

Mobility

• Can be transported by truck, trailer, ship, or crane
• Fast deployment to new sites within hours
• Ideal for temporary or rapidly shifting operations

Plug-and-Play Installation

• Pre-installed electrical system, burners, scrubber, ducting, and controls
• Only requires fuel and simple chimney placement on arrival
• Minimal on-site civil work

Operational Reliability

• Weatherproof container ensures stable operation
• Dust and moisture protection for burners and control panels
• Extended service life in outdoor conditions

Environmental Compliance

• Multi-stage wet scrubbing ensures clean exhaust
• Suitable for medical-waste treatment at international standards

Cost Efficiency

• No building construction required
• Rapid commissioning reduces downtime
• Low operator skill requirement

8. Conclusion

The HICLOVER TS50 Containerized Mobile Incineration System is a robust and field-proven waste-treatment solution engineered for high mobility, controlled medical-waste destruction, and clean emissions. Its modular containerized structure allows quick deployment, easy relocation, and long-term reliability—making it ideal for remote clinics, emergency missions, military operations, and small healthcare networks requiring safe, on-site waste disposal.
