HICLOVER Mobile Mini Incinerator – Pickup-Tow Rapid-Deployment Waste Disposal Unit (10–20 kg/hour)

HICLOVER Mobile Mini Incinerator – Pickup-Tow Rapid-Deployment Waste Disposal Unit (10–20 kg/hour)

The HICLOVER Mobile Mini Incinerator is a compact, trailer-mounted waste treatment solution engineered for fast deployment, on-site disposal, and full mobility. Designed to be easily towed by a standard pickup truck, this unit integrates HICLOVER’s proven combustion technology into a field-ready mobile platform ideal for solid waste, medical waste, and small animal/pet disposal in remote or temporary locations.

With a processing capacity of 10–20 kg/hour, diesel or LPG fuel options, and a total system weight of 1.5–2.5 tons, the unit balances efficiency, portability, and operational reliability—making it suitable for organizations that require immediate and environmentally responsible waste handling.

1. Core Technical Features

Processing Capacity

• 10–20 kg/hour
• Suitable for low-volume daily waste loads, emergency disposal, or supplemental treatment

Fuel Options

• Diesel burner (standard)
• LPG/Natural gas burner (optional)
• Optional Italy-brand burners for high-efficiency combustion

Combustion System

• Primary combustion chamber with durable refractory lining
• Secondary chamber reaching 850–1100°C for complete combustion
• Minimum 2-second flue gas retention time
• Optimized air supply for low-smoke, low-odor operation

Top-Loading Design

• Large insulated top door for easy loading
• Ideal for bags, medical trays, small carcasses, contaminated PPE, and mixed solid waste
• Counterweight or manual-winch assisted opening (depending on spec)

Control System

• PLC or digital control panel
• Automatic ignition and burner regulation
• Over-temperature and flame-failure protection
• Real-time temperature monitoring for both chambers
• Emergency stop and interlock safety design

Construction

• Heavy-duty steel body with high-temperature refractory
• Stainless or coated finish
• Integrated ash drawer for clean removal
• Reinforced trailer platform with safety locks and stabilizing legs

2. Mobile Trailer Advantages

True Pickup-Tow Mobility

• Fits most standard pickup truck towing systems
• Small footprint, easy to maneuver
• Suitable for off-road or rural routes: villages, farms, desert roads, camp areas

Rapid Deployment

• Delivered fully assembled—no installation required
• Ready to operate within minutes after leveling
• Runs with local power or optional portable generator

Self-Contained Waste Treatment

• Eliminates the need for transporting infectious or hazardous waste
• Reduces environmental and health risks in underserved areas
• Provides controlled thermal destruction immediately at the waste source

Stability & Safety

• Equipped with stabilizing legs for safe operation
• Low center of gravity for safe towing
• Protected wiring and burner system suitable for field conditions

3. Application Scenarios

Medical & Health Facilities

• Rural clinics
• Mobile medical stations
• Emergency vaccination missions
• Temporary field hospitals
• Isolation zones and quarantine facilities

Humanitarian Aid & Peacekeeping

• UN/NGO relief operations
• Refugee and IDP camps
• Conflict-zone medical outposts
• Disaster response and epidemic control

Veterinary & Animal-Related Use

• Pet cremation in rural communities
• Animal control departments
• Small-farm animal carcass disposal
• Disease-control and biosecurity operations

Municipal & Remote Communities

• Villages lacking central waste treatment
• Border checkpoints
• Island or mountain communities
• Remote mining, construction, and oilfield camps

Environmental & Emergency Response

• Rapid cleanup of contaminated waste
• Temporary waste stations during infrastructure work
• Remote landfill avoidance for sensitive areas

4. Key Advantages Unique to the HICLOVER Mobile Mini Unit

Compact & Portable

• Lightweight and tow-friendly (1.5–2.5 tons total)
• Fits tight spaces, narrow roads, and remote landscapes

High Integration

• Incinerator + chimney + burner + control panel all installed on one platform
• Ready-to-operate factory configuration
• No site construction or assembly required

Operational Safety

• Advanced burner control, temperature monitoring, and automatic regulation
• Insulated top-loading door reduces operator exposure
• Safe ash-handling design

Fuel Flexibility

• Compatible with diesel or LPG, ensuring usability worldwide
• Efficient fuel consumption and fast heat-up time

Cost-Effective

• Reduces transportation and handling of dangerous waste
• Minimal maintenance requirement
• Provides reliable long-term operation in harsh environments

Conclusion

The HICLOVER Mobile Mini Incinerator is an ideal solution for organizations seeking a compact, mobile, and highly efficient method for on-site waste disposal. Its 10–20 kg/hour capacity, diesel/LPG fuel flexibility, top-loading design, and fully integrated trailer-mounted structure make it an essential tool for medical missions, emergency response, rural communities, animal control, and humanitarian operations.

By bringing controlled waste treatment directly to the point of need, HICLOVER delivers a modern, practical, and safe approach to decentralized waste management worldwide.
