HICLOVER Mobile Incinerator Trailer Unit – Rapid-Deployment Waste Treatment for Field Operations (10–30 kg/hour)

HICLOVER Mobile Incinerator Trailer Unit – Rapid-Deployment Waste Treatment for Field Operations (10–30 kg/hour)

The HICLOVER mobile incinerator trailer unit is a compact, road-towing waste treatment solution designed for rapid response, onsite disposal, and full mobility. Installed on a reinforced 1.5–3-ton trailer chassis and towable by common pickup trucks, this system provides highly efficient thermal treatment for solid waste, medical waste, animal waste, and pet remains in remote or temporary locations.

This mobile configuration combines HICLOVER’s proven combustion technology with a field-ready transport platform, ensuring safer waste handling, reduced logistics pressure, and immediate onsite operation.

1. Core Performance Capabilities

Processing Capacity

• 10–30 kg/hour (ideal for daily small-scale operations)
• Designed for intermittent or continuous burning cycles depending on waste type

Fuel Options

• Diesel burner (standard)
• LPG/Natural gas burner (optional)
• High-efficiency Italy-brand burner options

Combustion System

• Primary combustion chamber for waste loading and initial burn
• Secondary chamber (afterburner) with 850–1200°C temperature range
• Minimum 2-second flue-gas retention to ensure clean and complete combustion

Control & Safety System

• PLC/Smart panel control
• Automatic temperature control
• Digital display for chamber temperature, burner status, and operating cycles
• Emergency stop, flame-sensor safety interlock, over-temperature protection

Construction

• Fully insulated refractory brick + castable lining
• Stainless steel or painted carbon-steel outer shell
• Reinforced trailer frame, parking brakes, and stabilizing legs

2. Trailer-Mounted Mobility Advantages

Rapid Deployment

• Towable by standard 4×4 pickup trucks
• Quick arrival to any site: disaster zones, remote villages, farms, military sites, temporary clinics
• Minimal setup time: leveling, power connection, ignition

True Plug-and-Operate

• Factory-assembled system
• No civil construction or foundations required
• Works with diesel generator or local power supply

Onsite Waste Destruction

• Eliminates long-distance waste transportation
• Prevents contamination and disease spread
• Ideal for decentralized waste management models

Compact Footprint

• Fits narrow roads, desert tracks, mountainous terrain
• Suitable for rural health centers, mobile hospitals, humanitarian missions

3. Key Features & Integration Options

Standard Features

• Manual or hydraulic top-loading lid
• Chimney stack with spark-arrestor design
• High-temperature refractories (up to 1750°C)
• Ash removal drawer
• Safety door interlock
• Adjustable air control for optimized combustion

Optional Add-Ons

• Wet scrubber
• Diesel generator set (3 kW)
• Work lights for night operation
• Fire-extinguishing kit
• Enclosed mini-toolbox or spare-parts kit

4. Typical Application Scenarios

Medical & Health

• Emergency field hospitals
• Rural clinics with low waste volume
• Vaccination & immunization stations
• Mobile laboratories

Humanitarian & Peacekeeping

• UN/WHO/NGO temporary medical locations
• Refugee camps
• Disaster-relief zones
• Crisis-response operations

Veterinary & Animal Control

• Animal remains disposal
• Pet cremation service in rural and suburban areas
• Livestock disease control (avian flu, ASF, etc.)

Municipal & Community

• Remote villages lacking central waste treatment
• Island communities
• Military camps, mining sites, oil camps
• Construction sites and isolated work zones

Environmental & Emergency Response

• Rapid deployment to control contaminated waste
• Clean-up of illegal dumpsites
• Emergency environmental incidents

5. Distinct Advantages of the HICLOVER Mobile System

Mobility

• Full towing capability by pickup trucks
• Moves instantly between locations
• Accessible in off-road terrain

Independence

• Operates without permanent buildings
• Optional generator makes it self-powered
• Complete waste-treatment solution in one trailer

Safety & Compliance

• Dual-chamber combustion with high-temperature control
• Meets WHO guidelines for medical waste
• Reduced smoke and odor through afterburning

Efficiency

• Fast heat-up and burn cycles
• Optimized fuel consumption
• Low maintenance design

Integration

• All components—incinerator, fuel system, chimney, control system—factory-mounted on one platform
• Ready for immediate international deployment

Conclusion

The HICLOVER mobile trailer-mounted incinerator provides a flexible, powerful, and safe onsite waste treatment solution for organizations that require immediate and efficient disposal capabilities. With a 10–30 kg/hour capacity, diesel/LPG fuel flexibility, and a robust 1.5–3-ton trailer architecture towable by standard pickup trucks, it is ideal for medical missions, emergency response, rural service, animal control, and field operations worldwide.

This compact, integrated, and highly mobile system offers a new standard for rapid-deployment waste management—bringing reliable HICLOVER technology directly to the point of need.
