HICLOVER Incinerator Model YD100: Advanced Waste Management with Intelligent Automation

The HICLOVER Incinerator Model YD100 is a robust solution engineered for high-capacity waste treatment. Whether handling medical waste in hospitals, processing municipal refuse, or managing animal cremation by-products, the YD100 stands out with its efficient combustion and environmentally friendly operation. With an integrated PLC (Programmable Logic Controller) automatic control system, this incinerator offers unparalleled operational safety and precision.

Overview

As part of HICLOVER’s distinguished YD series, the Model YD100 is designed to deliver a burning rate of around 100 kg per hour—making it ideally suited for facilities with substantial waste output. Its state-of-the-art PLC control system automates critical aspects of the incineration process, ensuring that parameters such as temperature, fuel input, and burn cycle duration are constantly monitored and adjusted for optimal performance.

Key Features and Design Highlights

• Dual Combustion Chambers:
  The YD100 utilizes a dual-chamber system—typically featuring a primary combustion chamber (approximately 1200 L) and a secondary chamber (around 500 L). This design ensures complete combustion, reducing residual waste and minimizing harmful emissions.

• PLC Automatic Control System:
  At the core of the YD100’s advanced functionality is its PLC automatic control system. This intelligent controller continuously monitors combustion conditions, automatically adjusting fuel input and managing burn cycles to maintain safe operating temperatures (typically 800℃–1000℃ in the primary chamber and 1000℃–1200℃ in the secondary chamber). This automation not only enhances energy efficiency but also significantly improves operational safety by reducing human intervention.

• Robust Construction and Durability:
  The incinerator’s combustion chambers are lined with high-grade refractory materials designed to withstand extreme temperatures and harsh operating conditions. In addition, the stainless steel chimney ensures efficient exhaust handling and long-term reliability. This rugged construction makes the YD100 a durable investment for continuous, high-volume waste management applications.
• Versatile Fuel Options:
  The YD100 is engineered to operate on either diesel oil or natural gas, allowing operators to choose the most cost-effective and locally available fuel source. Its efficient Italian-designed burner contributes to a high combustion efficiency—typically exceeding 98%—which minimizes fuel consumption and reduces environmental impact.

Technical Specifications (Approximate)

• Burning Rate: ~100 kg/hour
• Feed Capacity: Designed to accommodate high-volume waste loads, supporting facilities such as hospitals (e.g., handling waste from 500-sickbed operations)
• Voltage: Options available at 220V or 380V
• Power Consumption: Configured for high-capacity operation (specific power ratings may vary by installation)
• Chamber Volumes:
  • Primary Chamber: Approximately 1200 L
  • Secondary Chamber: Approximately 500 L
• Control System: Fully automated PLC with digital temperature monitoring and safety shutoff features
• Fuel Options: Diesel oil or natural gas with optimized consumption rates
• Construction Materials: High-grade refractory lining in combustion chambers; stainless steel chimney for reliable exhaust management
• Burning Efficiency: >98%
• Environmental Compliance: Designed to minimize harmful emissions through complete combustion and effective post-combustion treatment

Applications

The HICLOVER Incinerator Model YD100’s high performance and advanced automation make it suitable for various applications:

• Medical Waste Management: Ideal for hospitals and clinics that require safe, efficient, and hygienic disposal of biohazardous waste.
• Municipal Solid Waste: Well-suited for communities and municipalities needing a high-capacity incinerator with minimal manual oversight.
• Animal Cremation Services: The YD100 offers controlled and respectful incineration of animal remains, making it a reliable option for pet cremation facilities.

Operational Excellence and Environmental Benefits

The integration of the PLC automatic control system in the YD100 not only streamlines operations but also ensures consistent combustion quality and safety. By automating critical processes, the system reduces the risk of operator error, enhances fuel efficiency, and maintains optimal incineration conditions. This results in:

• Lower operational costs due to efficient fuel use
• Minimal residual ash and reduced need for extensive maintenance
• Compliance with strict environmental standards by limiting harmful emissions

Conclusion

The HICLOVER Incinerator Model YD100 with its advanced PLC automatic control system offers an efficient, reliable, and environmentally conscious solution for high-capacity waste management. Its dual combustion chambers, robust construction, and intelligent automation ensure that it meets the demanding needs of modern waste disposal—whether in healthcare, municipal, or pet cremation applications. As a trusted asset in waste management technology, the YD100 exemplifies the innovative engineering and commitment to environmental protection that HICLOVER is known for.

For further details or to explore customization options tailored to your facility’s specific waste management needs, please visit HICLOVER’s official website or contact their dedicated support team.
