HICLOVER Incinerator Model YD-20C: A Compact and Efficient Waste Treatment Solution

In the evolving field of waste management, efficient and reliable incineration technology is essential for healthcare, pet cremation, and small-scale municipal waste applications. The HICLOVER Incinerator Model YD-20C is engineered to meet these demands by offering a compact design, high burn efficiency, and robust performance—all wrapped in a user-friendly system.

Overview

The Model YD-20C is part of HICLOVER’s innovative range of small-scale incinerators. It is designed to treat various types of waste—ranging from medical and clinical waste to pet cremation residues—by ensuring complete combustion and minimal pollutant emissions. Its streamlined configuration and durable build make it an attractive option for facilities that require a reliable waste treatment system without the need for extensive installation or large-scale infrastructure.

Key Features and Design

• Dual Chamber System:
  The incinerator incorporates a primary combustion chamber (200 liters) and a post-combustion chamber (140 liters). This dual-chamber design ensures that waste is incinerated thoroughly, significantly reducing emissions and residual waste.
• High Temperature Operation:
  Operating at a solid chamber temperature of 800℃ to 1000℃ and a gas chamber temperature of 1000℃ to 1200℃, the YD-20C guarantees effective waste breakdown and pathogen destruction. The chamber’s refractory concrete lining further enhances its durability and heat retention.
• Efficient Burner System:
  Equipped with an Italian burner, the unit runs on either natural gas or diesel oil, offering operational flexibility depending on local fuel availability. Its efficient design contributes to a high burning efficiency—greater than 98%—ensuring minimal waste residue.
• User-Friendly Operation:
  The manual feed mode, combined with a straightforward control interface, makes the YD-20C easy to operate even in settings with limited technical support.

Technical Specifications

• Model: YD-20C
• Feed Capacity: 40–80 kgs per feed
• Burning Rate: 20 kgs per hour
• Burning Time per Feed: 2.0–4.0 hours
• Voltage: 220V
• Power: 0.50 kW
• Fuel Options: Natural Gas or Diesel Oil
• Burner: Italian design
• Feed Mode: Manual
• Fuel Consumption:
  • Oil: 5.4–12.6 kg/hour
  • Gas: 6.5–15.0 m³/hour
• External Dimensions: 170 x 140 x 160 cm (main body)
• Primary Chamber Internal Dimensions: 55 x 55 x 65 cm
• Waste Combustion Chamber: 200 Liters
• Post Combustion Chamber: 140 Liters
• Oil Tank Capacity: 100 Liters
• Door Opening: 38 x 48 cm
• Chimney: 5.0 meters
• Gross Weight: 1200 kgs
• Chamber Material: Refractory Concrete
• Maximum Heat Value: 126,000 Kcal/Hr
• Operational Temperatures:
  • Solid Chamber: 800℃–1000℃
  • Gas Chamber: 1000℃–1200℃
  • Chamber Anti-Rate: 1350℃
• Residency Time: 2.0 seconds
• Burning Efficiency: ＞98%
• Waste Lower Calorific Power: 3000 Kcal

Applications

The HICLOVER YD-20C is versatile enough for a variety of settings:

• Medical Facilities: Efficient for treating clinical and biohazardous waste, ensuring safe disposal in hospitals, clinics, and laboratories.
• Pet Cremation: Its controlled combustion process is well-suited for pet cremation services, offering respectful and hygienic handling of animal remains.
• Community Waste Management: Ideal for small-scale municipal or community waste processing, especially in areas where space and installation complexity are concerns.

Operational Excellence and Environmental Impact

Thanks to its high combustion temperatures and dual-chamber design, the YD-20C achieves complete incineration of waste. This process minimizes harmful emissions and reduces the environmental footprint of waste disposal operations. Its energy-efficient design, coupled with flexible fuel options, makes it a cost-effective choice for facilities looking to balance operational efficiency with environmental stewardship.

Conclusion

The HICLOVER Incinerator Model YD-20C stands out as a robust, compact solution for effective waste management. Whether for medical waste treatment, pet cremation, or small-scale community applications, its advanced design, high burning efficiency, and ease of operation make it a valuable asset for any facility. With its ability to handle a feed capacity of 40–80 kgs per cycle and a burning rate of 20 kgs per hour, the YD-20C offers reliable performance while maintaining environmental compliance.

For more detailed information or to discuss how the YD-20C can meet your specific waste management needs, please visit HICLOVER’s official website or contact their support team.
