HICLOVER Incinerator Model TS30: A Cutting‐Edge Solution for Efficient Waste Management

In today’s rapidly evolving waste management landscape, efficient and environmentally sound disposal methods are critical—especially in sensitive sectors such as medical waste and animal cremation. The HICLOVER Incinerator Model TS30 stands out as a compact yet powerful option, engineered to meet these needs with innovative design features and advanced control technology.

Overview of the TS30 Model

Developed by HICLOVER, a recognized leader in incineration technology, the TS30 model is specifically designed for the treatment of small to medium waste loads. Whether used in hospitals, clinics, or pet crematories, this incinerator is known for its robust performance, environmental safety, and operational simplicity. Its PLC (Programmable Logic Controller) based system allows for both automatic and manual operation, ensuring reliable and adaptive performance even under varying waste conditions.

Technical Specifications

The TS30 model is built with a focus on efficiency and safety. Key technical highlights include:

• Burn Rate & Feed Capacity:
  The incinerator maintains an average burn rate ranging from 30 to 50 kg/hour, with a feed capacity of about 60 kg per loading. This enables it to handle continuous operation while managing varying waste volumes effectively.

• Dual Combustion Chambers:
  Featuring a primary combustion chamber of 330 liters and a secondary chamber of 180 liters, the dual-chamber design ensures complete combustion of waste. The primary chamber operates at 800℃–1000℃, while the secondary chamber reaches temperatures between 1000℃–1200℃—a configuration that minimizes toxic emissions and improves burning efficiency.

• Control System & Monitoring:
  The incinerator uses a PLC-based control mode for precise regulation. With four digital temperature displays and built-in temperature protection, operators are provided with real-time monitoring and automatic shutdown capabilities to prevent overheating.
• Additional Features:
  Other specifications include a manual feed door (55 x 50 cm), a 220V power supply with a power rating of 0.5–1.0 kW depending on the configuration, and an optional oil tank (commonly available in 100L or 200L capacities). The structure is supported by a robust stainless steel chimney, typically around 5 meters in length, which aids in effective smoke management.


Design and Operational Advantages

The TS30’s thoughtful design is centered on operational simplicity and environmental compliance:

• Dual-Chamber Efficiency:
  The two-stage combustion process not only enhances waste destruction but also reduces the potential for secondary pollution. The brief residency time of around 2.0 seconds in the secondary chamber ensures that volatile emissions are completely oxidized.
• PLC Automation:
  The integration of a programmable logic controller brings advanced automation to the waste incineration process. This intelligent system allows for customized combustion cycles based on waste characteristics and operational demands, contributing to consistent performance and energy efficiency.
• Smoke Filtering and Emission Control:
  An integrated smoke filter chamber (often equipped with a dry scrubber) significantly reduces smoke and odor, contributing to a cleaner and safer operational environment. This is especially crucial in medical settings where strict environmental standards are in place.
  citeturn0search0

Applications and Use Cases

Owing to its versatile design, the HICLOVER TS30 is well-suited for:

• Medical Waste Disposal:
  Hospitals and clinics benefit from its ability to safely incinerate bio-hazardous waste, reducing the risk of infection and contamination.
• Animal Cremation:
  With its efficient combustion process, the TS30 is also adapted for pet cremation services, ensuring dignified and clean disposal of animal remains.
• General Solid Waste Management:
  The robust design and high burning efficiency make it an excellent choice for small-scale municipal waste treatment, particularly where space and resources are limited.

Environmental and Operational Benefits

The TS30 incinerator not only meets strict safety and environmental standards but also offers:

• High Burning Efficiency:
  The dual combustion chamber system ensures that nearly all waste is completely incinerated, maximizing energy utilization and minimizing ash residue.
• Reduced Emissions:
  The combination of high temperatures and an effective smoke filter chamber results in low emission levels, addressing environmental concerns and regulatory requirements.
• User-Friendly Operation:
  With its digital control system and automated safety features, the TS30 is designed for ease of use, requiring minimal technical expertise while maintaining rigorous safety standards.

Conclusion

The HICLOVER Incinerator Model TS30 is a prime example of modern waste management technology. With its robust design, precise PLC control, and advanced emission control features, it represents an effective and sustainable solution for medical, animal, and general solid waste disposal. Whether for a healthcare facility or a small waste management operation, the TS30 delivers reliability, efficiency, and environmental safety in a compact package.

For more detailed information and technical documents, please visit the HICLOVER website or contact their sales team directly.
