HICLOVER Incinerator Model TS10 with Wet Scrubber System

A Compact, Eco-Friendly Solution for Small-Scale Waste Management

In today’s increasingly eco-conscious environment, effective waste treatment systems must not only process waste efficiently but also minimize harmful emissions. The HICLOVER Incinerator Model TS10 is designed to meet these challenges head on. This compact incinerator, with a burning capacity of approximately 10 kg per hour, is ideal for small hospitals, clinics, laboratories, and pet cremation services. When paired with an integrated wet scrubber system, the TS10 offers exceptional emission control while ensuring safe and complete waste incineration.

Overview

The TS10 is part of HICLOVER’s acclaimed TS series of incinerators. Designed for small-scale operations, its streamlined build and user-friendly controls make it particularly suited to environments where space and budget are limited. What sets the TS10 apart is its integration of a wet scrubber system—a technology that plays a critical role in neutralizing harmful gases and particulate matter released during combustion.

Key Features and Design Highlights

• Compact and Efficient Operation:
  With a burning rate of about 10 kg per hour and a feed capacity typically around 20 kg per cycle, the TS10 is engineered for facilities that generate modest volumes of waste. Its compact size allows for installation in spaces where larger systems might be impractical.
• Dual Combustion Chamber Design:
  The TS10 features a dual chamber system comprising a primary combustion chamber (approximately 100 L with internal dimensions around 50×50×40 cm) and a secondary chamber (about 50 L). This configuration ensures that waste undergoes complete combustion, resulting in minimal residual ash and reduced emissions.
• Integrated Wet Scrubber System:
  One of the standout features of the TS10 is its wet scrubber system. As exhaust gases exit the combustion chambers, they pass through the scrubber where a water spray (often enhanced with alkaline additives) effectively captures and neutralizes acid gases and fine particulates. This process cools the gases and reduces the release of harmful emissions into the atmosphere, helping operators meet strict environmental standards.
• PLC-Based Control (Optional):
  While some TS10 models are designed for manual operation, many installations include a PLC (Programmable Logic Controller) to automate critical functions. This advanced control system monitors key parameters such as combustion temperature and fuel flow, optimizing the burn cycle and enhancing overall operational safety and energy efficiency.

Technical Specifications (Typical)

• Burning Rate: ~10 kg/hour
• Feed Capacity: ~20 kg per feed cycle
• Control Mode: Available in PLC-controlled configurations for automated operation
• Combustion Chamber:
  • Primary Chamber: ~100 L (internal dimensions: ~50×50×40 cm)
  • Secondary Chamber: ~50 L
• Voltage & Power: Operates on standard 220V supply; power consumption is optimized for small-scale incineration
• Wet Scrubber System:
  • Utilizes a water-based scrubber (with optional chemical additives) to capture and neutralize emissions
• Construction Materials: High-grade refractory lining for thermal resistance and a stainless steel exhaust system for durability and efficient gas handling
• Burning Efficiency: Designed to achieve high combustion efficiency (typically >98%), ensuring minimal waste residue

(Specifications are indicative and may be customized to meet specific application requirements.)

Applications and Benefits

The HICLOVER TS10 with a wet scrubber system offers several distinct advantages:

• Medical Waste Management:
  Ideal for small hospitals, clinics, and laboratories, the TS10 safely incinerates biohazardous waste while its wet scrubber system minimizes the emission of harmful pollutants.
• Pet Cremation:
  Pet crematoriums benefit from the TS10’s controlled, efficient burning process and reduced emissions, ensuring a respectful and environmentally sensitive treatment of animal remains.
• Small-Scale Municipal or Industrial Waste:
  Communities and small industrial facilities can utilize the TS10 to manage waste volumes effectively without investing in large-scale systems.
• Environmental Protection:
  The integrated wet scrubber significantly lowers the release of acid gases and particulate matter, aiding compliance with local environmental regulations and contributing to improved air quality.

Conclusion

The HICLOVER Incinerator Model TS10 with its integrated wet scrubber system represents an ideal solution for small-scale waste management needs. Its compact design, combined with efficient combustion and advanced emission control, makes it a valuable asset for facilities aiming to balance operational efficiency with environmental responsibility. Whether it’s for medical waste disposal, pet cremation, or managing municipal refuse, the TS10 delivers a reliable and eco-friendly incineration solution.

For more detailed specifications or to discuss customization options tailored to your facility’s unique needs, please visit HICLOVER’s official website or contact their dedicated support team.
