Fixed Dual-Chamber Incinerator HICLOVER TS150 PLC

Fixed Dual-Chamber Incinerator HICLOVER TS150 PLC

Power Supply: 220 V
Type: Fixed installation, dual combustion chambers
Control System: PLC automatic control
Model: HICLOVER TS150 PLC

Combustion System

Primary Chamber

Internal Volume: 1.5 m³

Fixed-bed structure with round steel grate and under-air supply

Operating Temperature: 850–950 °C

Secondary Chamber

Internal Volume: 0.75 m³

Operating Temperature: ≥1100 °C

Gas Residence Time: ≥2 seconds

Chimney

Standard: carbon steel outer shell with anti-corrosion coating

Optional Upgrade: stainless steel 304 shell, recommended for coastal installations (Djibouti)

Burner Configuration (Diesel Fuel)

Chamber	Burner Type	Quantity	Rated Fuel Use (Upper Limit)
Primary Chamber	G20LC (single-stage)	2 sets	≈18 kg/h total
Secondary Chamber	G20LC (single-stage)	1 set	≈16 kg/h

Total Peak Fuel Consumption: 34 kg/h (instantaneous maximum) — not for continuous operation.
Control Strategy: staged automatic control, start/stop by temperature setpoint.

Environmental Control & Options

Base Configuration: dual-chamber high-temperature combustion with dry-type alkaline gas neutralization.

Optional Packages:

Wet scrubber system for enhanced gas cleaning.

Stainless-steel 304 housing and stack for marine corrosion protection.

Summary:

The

HICLOVER TS150 PLC incinerator is a fixed dual-chamber system engineered for mixed solid waste in coastal regions such as Djibouti. It integrates stable high-temperature combustion, PLC automation, and flexible emission control options. The system achieves efficient waste reduction with low environmental impact, meeting operational and maintenance requirements for daily loads up to 700 kg.
