Burner Controller for Riello G20LC

HICLOVER TS5 Incinerator: Advanced Waste Management Solution

The HICLOVER TS5 PLC Incinerator is designed to meet the demanding needs of waste disposal, offering an efficient and reliable solution for various waste types, including industrial, medical, and animal waste. This high-performance incinerator is equipped with advanced features, making it one of the most sophisticated models available in the market. Below are the key details and specifications of the HICLOVER TS5 Incinerator.

Key Features and Specifications

1. Burn Rate and Feed Capacity:
   • Burn Rate (Average): 5-10 kg/hour
   • Feed Capacity (Average): 5-10 kg per feeding The TS5 is ideal for medium-scale waste disposal operations, with the flexibility to handle a variety of waste volumes efficiently.
2. Control Mode and Sensors:
   • Control Mode: Fully automatic with PLC control
   • Intelligent Sensors: Continuously feeding with worker protection, ensuring safety and operational efficiency. The PLC system allows for precise control of the incineration process, while the intelligent sensors guarantee that operations remain smooth and safe.
3. Temperature and Fuel Efficiency:
   • High Temperature Retention (HTR): Automatic and adjustable
   • Intelligent Fuel Saving Function: Helps optimize fuel usage, making the TS5 an energy-efficient choice.
   • Temperature Monitoring: Equipped with a temperature thermometer (corundum probe tube) capable of measuring up to 1400°C.
   • Automatic Cooling and Protection: Prevents overheating and ensures the safety of both the operator and equipment. These features ensure that the incinerator operates within optimal temperature ranges while minimizing energy consumption.
4. Combustion Chambers:
   • Primary Combustion Chamber: 52L (Internal Dimensions: 50x35x30cm)
   • Secondary Combustion Chamber: 26L
   • First Chamber Temperature: 800℃C1000℃
   • Second Chamber Temperature: 1000℃C1300℃ The robust design of the combustion chambers enables the TS5 to handle high volumes of waste efficiently, ensuring complete combustion and minimal environmental impact.
5. Burner and Fuel Consumption:
   • Burner Type: Italy Brand burner
   • Oil Consumption: 4 kg/hour
   • Natural Gas Consumption: 6 m³n/hour The high-quality Italy brand burner ensures optimal burning efficiency while keeping fuel consumption under control.
6. Advanced Safety Features:
   • Automatic False Alarm: Alerts users to any malfunctions or abnormalities.
   • Automatic Protection Operator (APO): Ensures safety by protecting the operator from potential hazards.
   • System Testing Mode: Allows users to test and ensure all systems are functioning correctly. These built-in safety features make the TS5 a reliable and secure choice for waste disposal.
7. Additional Features:
   • Wet Scrubber: Optional for enhanced smoke filtration and environmental protection.
   • Chimney: 4 meters long, made of high-grade stainless steel 304 for durability.
   • Feeding Door: Standard side feeding door, with options for front or top loading.
   • Oil Tank Capacity: 200L with a liquid level display for easy monitoring.
   • Progress and Timing Display: LCD display for tracking incineration progress and timing.
   • External Dimensions: 120x80x110 cm, with a total gross weight of 1300 kg, making the TS5 compact yet powerful.
8. Certifications and Compliance:
   • CE Certificate: Compliant with CE (2006/42/EC, 2014/30/EU) standards.
   • ISO9001:2015 Certificate: Ensures manufacturing quality and consistency.
   • High-tech Enterprise Certificate: Recognized for its advanced technological capabilities. These certifications highlight the TS5’s adherence to international safety and quality standards.

Optional Features

• Wet Scrubber: For improved filtration, an optional spray tower and defogging tower can be added, reducing emissions and ensuring compliance with environmental standards.
• Containerized Mobile Type: This option enables the incinerator to be mounted on a mobile container, making it ideal for remote or crisis areas.
• Top Feeding Door: For ease of waste loading from the top, perfect for large-volume waste disposal.
• Trailer or DC-Power Vehicle: For mobility and ease of transport.

Applications

The HICLOVER TS5 PLC Incinerator is suitable for various waste disposal applications, including:

• Medical Waste: Hospitals and medical facilities can rely on the TS5 to safely and efficiently dispose of hazardous medical waste.
• Industrial Waste: Ideal for industries looking to manage paper, plastic, and other non-hazardous waste.
• Animal and Pet Waste: Provides a reliable solution for cremating animal remains or other organic waste.
• Crisis and Remote Areas: With its containerized mobile option, the TS5 is well-suited for disaster relief zones, camps, or any situation where waste management is critical.

Conclusion

The HICLOVER TS5 PLC Incinerator is a highly efficient, reliable, and safe waste management solution. With its advanced features, energy-saving functions, and customizable options, it meets the needs of various industries, hospitals, and remote locations. Its robust construction, coupled with high-tech automation and safety systems, ensures optimal performance and long-term durability.

For more information on the HICLOVER TS5 Incinerator or to request a quote, visit www.hiclover.com or contact us directly.
