Baltur BTL10 Diesel Burner
$799.00
Burner
Baltur BTL10 Diesel Burner
Baltur BTL10 Diesel Burner
Store Link: https://www.haiwos.com/ ***Product Details (***Please Sign In or Login to "My Account". Price is the EXW Factory Term price or send email to us get discount if possible and get shipping cost for delivery by CIF/C&F/FOB term: sales@hiclover.com***) WhatsApp on Mobile: +8613813931455
Baltur BTL10 Diesel Burner – Technical Overview
Baltur BTL10 is a compact, reliable, and energy-efficient diesel oil burner designed and manufactured in Italy by Baltur S.p.A., a well-known European burner specialist. The BTL10 is suitable for small to medium-sized boilers, incinerators, and hot-water systems, offering stable combustion and easy maintenance.
Key Features
- High combustion efficiency with optimized fuel-air mixing.
- Compact design for easy installation in limited spaces.
- Automatic ignition and flame monitoring via photoelectric cell.
- Low noise operation and reliable mechanical structure.
- CE certified and compliant with European safety standards.
Technical Data (Typical)
- Model: Baltur BTL10
- Fuel type: Light oil (Diesel)
- Ignition: Automatic, with high-voltage transformer
- Control: Fully automatic operation with safety shutdown
| Specification | Details |
|---|---|
| Thermal Power | 60.2 – 118.0 kW |
| Fuel Flow Rate | ~5.1 – 9.9 kg/h |
| Electrical Supply | 1N AC, 230 V @ 50 Hz (also 220 V/60 Hz) |
| Motor Power | ~0.1 – 0.11 kW |
| Dimensions (L×W×H) | 560 × 310 × 350 mm |
| Weight | ~12 kg |
| Operation Mode | Single-stage (on/off) |
| Air Damper | Manual or electric; full closure on shutdown |
| Fuel System | Gear pump with pressure regulation; optional pre-heater |
| Flame Detection | Photoresistor (plus ionization electrode) |
| Protection & Covering | IP40, sound-proof plastic casing |
| Compliance Standards | EN 267, EMC, LVD, Machinery Directive |
Applications
- Small steam boilers
- Hot-water boilers
- Waste incinerators
- Industrial ovens and heating systems
-
Key Technical Specifications
- Thermal Power Output:
- Minimum: 60.2 kW
- Maximum: 118.0 kW
- Fuel Flow Rate:
- Minimum: ≈5.1 kg/h
- Maximum: ≈9.9 kg/h
- Electrical Requirements:
- Supply: Single-phase (1N AC)
- Voltage: 230 V at 50 Hz (also available at 220 V/60 Hz version)
- Motor Power: ~0.1–0.11 kW
- Physical Dimensions & Weight:
- Dimensions (L×W×H): ≈560 × 310 × 350 mm
- Weight: ~12 kg
- Operation & Features:
- Single-stage (on/off) operation
- Combustion air: Manual or electric damper, with full closure on shutdown to prevent heat loss
- Combustion head: Adjustable and removable without detaching burner from boiler
- Fuel supply: Gear pump with pressure regulator and shut-off valves. “H” version includes light oil pre-heater
- Flame detection: Via photoresistor (photocell); some models include ionization electrode
- Protection & Covers: IP40 rated electrical enclosure and sound-insulated plastic housing
- Standards Compliance: Meets EN 267, EMC and LVD Directives, and Machinery Directive
The Baltur BTL10 diesel burner is a robust and efficient solution for users requiring consistent combustion in small to mid-range heating applications. With Italian engineering and strict quality control, it ensures stable performance, low emissions, and easy servicing.
