Automatic Roll Filters Machine for Air Conditioning Ventilation System Winding Air Filter
$5 012.00
Air Filter
Automatic Roll Filters Machine for Air Conditioning Ventilation System Winding Air Filter
Automatic Roll Filters Machine for Air Conditioning Ventilation System Winding Air Filter
Store Link: https://www.haiwos.com/ ***Product Details (***Please Sign In or Login to "My Account". Price is the EXW Factory Term price or send email to us get discount if possible and get shipping cost for delivery by CIF/C&F/FOB term: sales@hiclover.com***) WhatsApp on Mobile: +8613813931455
Automatic Roll Filters Machine for Air Conditioning Ventilation System Winding Air Filter
What’s Automatic Roll Air Filter?
Automatic Roll Air Filters are advanced air filtration systems designed to maintain clean and efficient airflow in HVAC and industrial applications. These filters use a roll of media that automatically advances when the current section becomes clogged, ensuring uninterrupted performance and reducing maintenance needs. Commonly used in commercial buildings, factories, power plants, and clean rooms, they improve air quality, protect equipment, and enhance energy efficiency. Their self-advancing design makes them ideal for environments requiring reliable and low-maintenance filtration solutions.
.png)
| Frame material: |
Powder coating galvanized steel sheets/Stainless steel
|
| Filter media: |
Polyester synthetic fiber,G3, G4 (EN779) efficiency
|
| Power: |
as requirements
|
| Customized size: |
Available
|
| Application: |
Automatic roll filter is widely used to pre-filter of inductrial ventilation and air
conditioner ventilation system. It's suitable for high dust capacity environment and the
environments needs frequently change the filter material and constant air flow.
|
| Advantage: |
1.Using metal as he overall material,firm and reliable,meet the poorest working environments
2.Intelligent filter replacement system , effective energy conservation , reduce costs
3.Modular design to meet any type of system design and installation requirements
4.Low high-end options for different materials and configurations to meet the needs of
different customers.
|
There is a new material boxlocated on the top of the equipment.The initial pressure drop will increase when masses of high contcentration dirty air brought in,and when the initial pressure drip reches final pressure drop,the differential pressure switches opens,the switch will send signal to the control system,motor will work automatically,the dirty filter matrial will be wind onto the lower spool,at the same time clean filter material will take place of the dirty material.
.png)
|
Structure |
Galv. Steel sheet orstainless steelon request |
|
Working limits: |
Max temperature 80°C Max relative humidity 90% Max air velocity 2,8 m/s |
|
Width |
540 - 690 - 835 - 985 - 1140 - 1295 - 1450 - 1595 - 1740 - 1830 - 2000 - 2130 mm |
|
Height |
1000-5000mm |
|
Efficiency |
G3 G4 |
|
Different dimensions can be availableOn request |
|
Product features
* A complete air filter is assembled (includingmedia box, filter media, vertical column,holding bar, etc.)
* Transmission mechanism
* Control box
* Dropout voltage switch
* Internal connection cable
1: Using metal as he overall material,firm and reliable,meet the poorest working environments
2: Intelligent filter replacement system , effective energy conservation , reduce costs
3: Modular design to meet any type of system design and installation requirements
4: Low high-end options for different materials and configurations to meet the needs of different customers
.png)
Product applications
The automatic roll filter is mainly used for the air filtration of the air inlet in the blower room to prevent clogging of the filter system of the blower and prolong its service life.
Primary filtration of industrial ventilation and air conditioning systems.
The automatic roll filter iscompletely made of pressed and bent galvanized steel sheet.
All the part are assembled by steel bolts and rivets.
The filter is generally furnished completely assembled in the factory ready for installation in duct or plenum.
On request the filter can be supplied in a few preassebled components for transport or final plant reasons.
The filtering media is composed of glass fibers, normally with dust binding agent, or of synthetic fibers wound on a spool and enclosed in the top section of the filter with protective cover.
The movement of the filter media downward is given by a motor reducer located in the frontal bottom part of the filter in order to assemble the proper number of sections and to make checking and service operations easier.
In the lower part is located the disposables pool on which the dirty media is rolled automatically.
Advantages
1. The cabinet is made of metal which is sturdy and reliable. It can meet the harshest working environment.
2. Photoelectric control is used in this machine.It also adopet large LCD screen to display the running status, on-site sound and light alarm, and timely remind to replace the new filter material. And reserve a remote alarm interface for remote control.
3.Modular assembly and intelligent filter material replacement system, can operate more economically.
4.It is suitable for various ventilation and air intake purification occasions, especially for the air purification effect of low pressure and large air volume air supply system.
2. Photoelectric control is used in this machine.It also adopet large LCD screen to display the running status, on-site sound and light alarm, and timely remind to replace the new filter material. And reserve a remote alarm interface for remote control.
3.Modular assembly and intelligent filter material replacement system, can operate more economically.
4.It is suitable for various ventilation and air intake purification occasions, especially for the air purification effect of low pressure and large air volume air supply system.
Application
1. Inlet air filtration of blower in sewage treatment plant
2. Air conditioning return air filtration in textile mills
3. Industrial ventilation for equipment cooling
4. Central air conditioning air inlet system pre-filtering
5. Purification of sintering system in metallurgical industry
6. Pre-filtering of gas turbine air inlet system in power plants
7. Expressway equipment room or culvert ventilation
8. Ventilation of subway and civil air defense projects
9. Large air volume ventilation in tunnels in the coal industry
Type
1. Height series (mm): 1500, 1800, 2100, 2400, 2700, 3000, 3300, 3600, 4000, 4500, 5000
2. Width series (mm): 900, 1000, 1200, 1500, 1800, 2000, 2100
3. Air flow range (m3/h): 4000-250000
4. Depth dimension (mm): 500-650
Features:
1. The overall use of metal structure, strong and reliable, can meet the harshest working environment.
2. The CHF automatic winding filter adopts photoelectric control, which truly realizes the precise control of the rolling shutter filter material.
3. The photoelectric control adopts a large LCD screen to display the running status, and local sound and light alarms to remind you to replace the new filter material in time. Reserve a remote alarm interface for remote control.
4. Modular assembly, intelligent filter material replacement system, can meet the most complex airflow system requirements, effectively save energy, reduce manpower, and operate more economically.
